Product description
The level of competition in the scrap steel shearing machine industry is relatively fierce, and it is currently in a relatively mature stage of development. Henan Yuantong Machinery is one of the earliest manufacturers to enter the scrap steel shearing machine industry. It occupies a place in the scrap steel shearing machine industry. It is one of the companies with diversified product varieties and series in the scrap steel equipment processing enterprises. The gantry shears produced by Yuantong Machinery have a tonnage of 300-1800 tons of conventional models, and the width of the cutting mouth is 600-2200mm. It is suitable for light and thin steel, steel, steel, nickel, steel, round steel, steel pipe, scrap copper, Scrap steel, scrap iron, light metal structural parts, stainless steel, metal briquette, automobile body, aluminum alloy, copper, iron filings, steel wire, automobile, metal briquette and other scrap steel crushing equipment can not handle heavy waste and winding materials Processing.
Features of scrap steel hydraulic gantry shearing machine:
1. The hydraulic gantry shearing machine adopts hydraulic transmission. Compared with the mechanical transmission type shearing machine, it has the advantages of small size, light weight, low inertia, low noise, stable movement, convenient operation, flexible, large cutting surface, and convenient adjustment of the scissors mouth. And other advantages, reliable operation and use, easy to achieve overload protection.
2. The gantry shearing machine has manual, automatic, and remote control functions. The operation and control are convenient and simple. The scissors mouth can start and stop at any position in the working process, and can control the cutting mouth arbitrarily according to the size of the material to be cut In order to obtain economic work efficiency.
3. The gantry shearing machine is designed with a fast type. Under the condition of not increasing the power of the motor and the displacement of the oil pump, the speed is kept fast under the shearing (about 400-1600 tons), and the speed will be automatically changed when cutting large materials. Restore the original shear force, thereby improving work efficiency nearly doubled.
4. Gantry shearing machine is equipped with quick device. Without increasing the power of the motor and the displacement of the oil pump, a fast loop is designed to increase the shearing speed from 8 times per minute to 12 times per minute (referring to the number of times the scissors open the mouth), which nearly doubles the work efficiency.
Technical parameter
| Model | Shear Force (t) | Blade length (mm) | Shear Frequency (times/min) | Power (kw) | Working pressure (Mpa) | Bin size (mm) |
| Q91Y-315 | 315 | ≤1200 | 3-5 | 60 | 28 | 5000*1100*550(750) |
| Q91Y-400 | 400 | ≤1500 | 3-5 | 80 | 28 | 6000*1300*650(850) |
| Q91Y-500 | 50 | ≤1600 | 3-5 | 80 | 28 | 6000*1500*750(950) |
| Q91Y-630 | 630 | ≤1800 | 3-5 | 135 | 28 | 8000*1700*800(1100) |
| Q91Y-800 | 800 | ≤2000 | 3 | 180 | 28 | 8000*1900*900(1200) |
| Q91Y-1000 | 1000 | ≤3000 | 3 | 270 | 28 | 8000*2900*900(1200) |
| Q91Y-1250 | 1250 | ≤3000 | 3 | 315 | 28 | 8000*2900*900(1200) |
| Q91Y-1500 | 1500 | ≤3000 | 3 | 450 | 28 | 8000*2900*1000(1300) |
| Q91Y-2000 | 2000 | ≤3000 | 3 | 540 | 28 | 8000*2900*1100(1400) |
| Parameters are for reference only. If you need detailed data, please contact us. Contact information: +8613253576129 hnytzgjx@163.com | ||||||
FAQ
1. How many days do you need to produce this machine?
This is a machine specially designed and manufactured according to your specific requirements. From engineer design to production completion, it takes about 60 working days.
2. What does your factory do in terms of quality control?
We attach great importance to quality control and production from the purchase of steel plates to the final safety commissioning. Each machine will be fully assembled and carefully tested before shipment.
3. What is the quality assurance of your machine?
The quality assurance period is one year, and we choose components from world-renowned brands to keep our machines in ideal working conditions.
4. Can you install and debug abroad? How long will it take?
Yes, we provide overseas services, but you need to pay the engineer’s air ticket and hotel food expenses. Small equzpment usually take 5 working days, and large equipment usually take 20 working days.
Why choose Yuantong
• Henan metal crushing equipment manufacturer
• 15 years of professional production experience, the brand is trustworthy
• With independent production and processing centers, products are exported to more than 70 countries and regions at home and abroad
• The skilled technology of front-line employees provides guarantee for products
• With dozens of unique craftsmanship, it has been praised by "Customers are trustworthy"
• Advanced environmental protection spraying equipment to ensure the beautiful appearance of the equipment
• Professional after-sales team to serve you and escort your production
• Safe and efficient logistics distribution center to ensure accurate and timely delivery of equipment
• Provide you with a full range of installation and commissioning and personnel operation training
