Product description
Metal Crusher
The metal crusher is a new product developed by Yuantong Heavy Machinery over the years, which is favoured by metal recycling customers. The metal crusher does not require much investment cost, as long as the products belonging to the metal class can be related to the work of crushing, wide range of adaptability, and the crushed material can also be set according to the needs of the specifications, but also does not require complex operating procedures. Can be used for waste colour steel tiles, cans, paint buckets, motorbike frames, bicycle frames, old batteries, tin and other crushing, crushing materials in the crushing chamber into fine particles of particles for smelting steel and other to provide excellent raw materials to achieve the recycling of resources, the source of heavy machinery metal crusher is the recycling of scrap metal recycling is a very favourable solution.
Composition of metal crusher
The metal crusher consists of motor, shell, liner, hammer head (cutter head), rotor frame, rotor disc, pulley and so on.
Metal crusher working principle
The basic principle of the scrap crusher is to use the hammer to hit, driven by the high-speed high-torque motor, the hammer on the rotor of the host takes turns to hit the material to be crushed into the cavity, through the space formed between the liner plate and the hammer, the material to be crushed in the crushing cavity can be fully and effectively broken, and the material to be crushed will be torn to the specification of the crushed material. The crushed material passes through the air gyratory sorting system, separating the metal and non-metal, and the whole system of the metal crusher is equipped with a dust removal device, which minimises the danger of dust pollution produced in the production process.
Metal crusher features
1、Reasonable design and excellent manufacture prolong the service life of the equipment and reduce the maintenance cost of the equipment.
2、Hammer head adjustable, the material are made of special alloy material, wear-resistant and impact resistance.
3、Motor drive reduces power consumption by 20% compared with the motor consumption of similar products, and is equipped with overload protection for electrical appliances.
4、Control buttons allow you to control more simple, the entire crushing process can be only one person.
5, because we are manufacturers, can provide you with OEM processing, so the price is more advantageous, quality assurance, and our service is perfect, you buy the package of comfort with peace of mind.
Technical parameter
| Model | Power (kw) | Inlet width (mm) | Output size (mm) | Output (t/h) | Matching Transformer | |
| YTP-37 | 37 | 600 | 20-50 | ≈0.5 | 100KVA | |
| YTP-45 | 45 | 800 | 20-60 | ≈1 | 100KVA | |
| YTP-55 | 55 | 1000 | 20-60 | ≈1.2-1.5 | 100KVA | |
| YTP-75 | 75 | 1000 | 20-60 | ≈1.5-2 | 125KVA | |
| YTP-110 | 110 | 1300 | 30-60 | ≈2-3 | 250KVA | |
| YTP-132 | 132 | 1300 | 30-80 | ≈3-4 | 250KVA | |
| YTP-200 | 200 | 1600 | 30-80 | ≈3-5 | 250KVA | |
| YTP-280 | 280 | 1600 | 40-80 | ≈4-6 | 315KVA | |
| YTP-315 | 315 | 1800 | 40-80 | ≈6-8 | 400KVA | |
| YTP-450 | 450 | 2000 | 50-100 | ≈8-10 | 630KVA | |
| YTP-630 | 630 | 2000 | 50-120 | ≈10-13 | 800KVA | |
| YTP-710 | 710 | 2000 | 50-120 | ≈12-15 | 10KV High voltage | |
| Parameters are for reference only. If you need detailed data, please contact us. Contact information: +8613253576129 hnytzgjx@163.com | ||||||
FAQ
1. How many days do you need to produce this machine?
This is a machine specially designed and manufactured according to your specific requirements. From engineer design to production completion, it takes about 60 working days.
2. What does your factory do in terms of quality control?
We attach great importance to quality control and production from the purchase of steel plates to the final safety commissioning. Each machine will be fully assembled and carefully tested before shipment.
3. What is the quality assurance of your machine?
The quality assurance period is one year, and we choose components from world-renowned brands to keep our machines in ideal working conditions.
4. Can you install and debug abroad? How long will it take?
Yes, we provide overseas services, but you need to pay the engineer’s air ticket and hotel food expenses. Small equzpment usually take 5 working days, and large equipment usually take 20 working days.
