Product description
Features of scrap iron hydraulic gantry shearing machine:
1. The gantry shearing machine adopts hydraulic transmission. Compared with the mechanical transmission type shearing machine, it has the advantages of small size, light weight, low inertia, low noise, stable movement, convenient operation, flexible, large cutting surface, and convenient adjustment of the scissors mouth. And other advantages, reliable operation and use, easy to achieve overload protection.
2. The gantry shearing machine has manual, automatic, and remote control functions. The operation and control are convenient and simple. The scissors mouth can start and stop at any position in the working process, and can control the cutting mouth arbitrarily according to the size of the material to be cut In order to obtain economic work efficiency.
3. The gantry shearing machine is designed with a fast type. Under the condition of not increasing the power of the motor and the displacement of the oil pump, the speed is kept fast under the shearing (about 400-1600 tons), and the speed will be automatically changed when cutting large materials. Restore the original shear force, thereby improving work efficiency nearly doubled.
4. Gantry shearing machine is equipped with quick device. Without increasing the power of the motor and the displacement of the oil pump, a fast loop is designed to increase the shearing speed from 3 times per minute to 5 times per minute (referring to the number of times the scissors open the mouth), which nearly doubles the work efficiency.
Precautions for starting the metal hydraulic gantry shearing machine
1. Start the hydraulic gantry shearing machine for a few cycles of idling to ensure that under normal conditions, try to cut sheets of different thicknesses, from thin to thick. Ensure that the user is familiar with the performance of the shears.
2. It is necessary to adjust the gap of different blades when the thickness of the plate is different during the trial cutting. If the corresponding blade gap is not adjusted, the durability of the blade will be affected.
3. Turn on the pressure gauge switch during the cutting process of the hydraulic gantry shearing machine and observe the pressure value of the oil circuit. The pressure should be less than 20MPa when cutting a 12mm plate. the user needs to comply with this regulation, and the material that exceeds the specified thickness and cannot be cut can not be cut, causing damage to the machine.
4. Sound balance during operation. If the hydraulic gantry shearing machine has noise, stop and check.
5. When the hydraulic gantry shearing machine is operating, it will shut down and rest when the fuel tank temperature is 60 degrees.
Technical parameter
| Model | Shear Force (t) | Blade length (mm) | Shear Frequency (times/min) | Power (kw) | Working pressure (Mpa) | Bin size (mm) |
| Q91Y-315 | 315 | ≤1200 | 3-5 | 60 | 28 | 5000*1100*550(750) |
| Q91Y-400 | 400 | ≤1500 | 3-5 | 80 | 28 | 6000*1300*650(850) |
| Q91Y-500 | 50 | ≤1600 | 3-5 | 80 | 28 | 6000*1500*750(950) |
| Q91Y-630 | 630 | ≤1800 | 3-5 | 135 | 28 | 8000*1700*800(1100) |
| Q91Y-800 | 800 | ≤2000 | 3 | 180 | 28 | 8000*1900*900(1200) |
| Q91Y-1000 | 1000 | ≤3000 | 3 | 270 | 28 | 8000*2900*900(1200) |
| Q91Y-1250 | 1250 | ≤3000 | 3 | 315 | 28 | 8000*2900*900(1200) |
| Q91Y-1500 | 1500 | ≤3000 | 3 | 450 | 28 | 8000*2900*1000(1300) |
| Q91Y-2000 | 2000 | ≤3000 | 3 | 540 | 28 | 8000*2900*1100(1400) |
| Parameters are for reference only. If you need detailed data, please contact us. Contact information: +8613253576129 hnytzgjx@163.com | ||||||
FAQ
1. How many days do you need to produce this machine?
This is a machine specially designed and manufactured according to your specific requirements. From engineer design to production completion, it takes about 60 working days.
2. What does your factory do in terms of quality control?
We attach great importance to quality control and production from the purchase of steel plates to the final safety commissioning. Each machine will be fully assembled and carefully tested before shipment.
3. What is the quality assurance of your machine?
The quality assurance period is one year, and we choose components from world-renowned brands to keep our machines in ideal working conditions.
4. Can you install and debug abroad? How long will it take?
Yes, we provide overseas services, but you need to pay the engineer’s air ticket and hotel food expenses. Small equzpment usually take 5 working days, and large equipment usually take 20 working days.
